Post PCI Assessment - Cardiology Apps

Stent Expansion = MSA/Average Reference Lumen Area * 100

Can be performed automatically using the lumen profile feature which provides minimal stent area (MSA) and reference lumen area. Stent percent expansion is calculated via these measurements using the formula above.

Ask the Experts

We are ready to help you.
ask now

Take Quiz

Know about OCT? Test your knowledge.
try it now

Meet the Team

Read about the team behind the apps.
learn more

Contact Us

Reach out to us with general comments or questions.
connect now

Model	Burst (ATM)	Diameter (mm)	Balloon Length (mm)
			6	8	12	15	20	25	30
MINI TREK (CTO INDICATED)	1.27	1.2	✓	✓	✓	✓	✓
	1.56	1.5	✓	✓	✓	✓	✓
	2.17	2	✓	✓	✓	✓	✓	✓*	✓*
TREK	2.37	2.25	✓	✓	✓	✓	✓	✓	✓
	2.67	2.5	✓	✓	✓	✓	✓	✓	✓
	2.91	2.75	✓	✓	✓	✓	✓	✓	✓
	3.11	3	✓	✓	✓	✓	✓	✓	✓
	3.5	3.25	✓	✓	✓	✓	✓	✓	✓
	3.7	3.5	✓	✓	✓	✓	✓	✓	✓
	3.94	3.75	✓	✓	✓	✓	✓	✓	✓
	4.32	4	✓	✓	✓	✓	✓	✓	✓
	4.86	4.5			✓	✓
	5.36	5			✓	✓
*Only available as RX, not as OTW. Other sizes available in both versions.
Retrieved on April 07 2022 from Abbott product ordering information. Please look at the company's files for the latest available data on device configurations and avilability in your area.
